• Production Capacity：200,Y
• HS Code：8454309000
• Model NO.：H,130

Basic Info.

Model NO. H/130 HS Code 8454309000 Production Capacity 200/Y

Product Description

Clamping Force	KN	1300
Open stroke	mm	350
Space between Tie-bar	mm	430*430
Die-thickness(Min-Max)	mm	250-500
Injection Force	KN	100
Injection stroke	mm	148
Injection position	mm	0-80
Ejector force	KN	90
Ejector stroke	mm	85
Sleeve diameter	mm	60
Pump pressure	Mpa	12
Motor power	KW	11
Injection weight	Kg	2.5
Pot capacity	Kg	350
Tank capacity	L	450
Machine weight	Kg	5500
Dimension of machine	mm	5200*1600*2300
