• Production Capacity：200,Y
• HS Code：8454309000
• Model NO.：H,90

Basic Info.

Model NO. H/90 HS Code 8454309000 Production Capacity 200/Y

Product Description

Clamping Force	KN	900
Open stroke	mm	270
Space between Tie-bar	mm	360*360
Die-thickness(Min-Max)	mm	120-360
Injection Force	KN	75
Injection stroke	mm	130
Injection position	mm	0-60
Ejector force	KN	60
Ejector stroke	mm	60
Sleeve diameter	mm	60
Pump pressure	Mpa	12
Motor power	KW	11
Injection weight	Kg	1.6
Pot capacity	Kg	350
Tank capacity	L	250
Machine weight	Kg	4700
Dimension of machine	mm	4300*1800*2250
