• Coating：Sodium silicate
• Machining Tolerance：+,-0.01mm
• Standard：AISI
• Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Name：Slag Pot
• Slag Pots in Cast Steel：Heavy Fabrication Division
• Materia：DIN 17182 GS-16mn5 1.1131
• Fact Cubage：22 Cbm
• Weight：10 -100 T
• Product Application：Slag Pot in Steel Works.
• Cast Tolerance：Unless Otherwise ASTM, En, DIN, ISO, JIS, GB
• Pattern：New Natural Wooden Mold;
• Quality Inspection：Chemical Analysis; -Mechanical Performance; -Dim
• Transport Package：Slag Pots in Cast Steel & Slag Ladle
• Specification：Slag Pots in Cast Steel & Slag Ladle
• Trademark：CITICIC
• Origin：Luoyang, Henan
• Production Capacity：2000PCS,Year

Feature:
Material: steel, self-smelting according to standard: ASTM, EN, DIN,ISO, JIS, GB, etc;
Sand mold casting: Steel casting, through sodium silicated-bonded sand and/or resin sand;
Pattern: new natural wooden mold;
Non-destructive examination:
-visual detection ;
-Ultrasonic test ;
-Magnetic particle inspection ;
Quality inspection:
-Chemical analysis;
-Mechanical performance;
-Dimension report;
Cast Tolerance: unless otherwise  ASTM, EN, DIN,ISO, JIS, GB
Machining tolerance: unless otherwise according to dwg. requirement;


We are a modern industrial China group specialized in the producing of heavy plates
in low-alloyed carbon steel grades. Organised as full integrated works, the major production facilities
include cokery plant, blast-furnaces, oxygen steelplant - equipped with BOF-converters, secondary
metallurgy, vacuum degassing, continuous and ingots casting - and plate mills.
Complementary to the core business, a "down-stream" manufacturing unit is available as a branch of the
Heavy Fabrication: it is mainly focused on the supply of slag-pots made out of cast-steel (GS)
everywhere the emphasis is placed on large buckets in capacity up to 45 m³
(1.575 cu. feet).
The expertise of CITICIC  arises from its privilege to be both user and manufacturer of slag
pots. The extensive experience gained in designing and engineering slag-pots is primarily based on the
pots operating at the own steel plant and secondly on about 3.000 items produced over the 40 last years
also in co-operation with manufacturers of slag pot carriers and service providers to metallurgical
industries.
The Dillinger slag pots are operating worldwide whereverreliable tools are required for the disposal of
molten or solid slag which arises from metallurgical or chemical processes.
Heavy Fabrication Division
Product definition
The product covered here is a load-bearing device whose sole purpose is to collect molten or solid slag
generated during metallurgical or chemical processes, to retain it during transport and to deposit it at a
place of disposal.
Slag pots are crucial items as they are part of a lifting equipment and therefore undergo in terms of
mechanical design engineering and handling the national safety regulations of the state where they are
supposed to be operated. The design of the Dillinger slag pots intended to be used within the European
Community meets the requirements ofthe European Machinery Directive 2006/42/EC: every slag pots is
supplied with the CE conformity marking.
Material
The pots are made out of the cast-steel DICAST, trade name owned by CITICIC for
castings: this material is similar to the steels A27/A 27M grade 65-35: April 2003, BS 3100 A1/A2:
January 1991 or GS 20Mn5 to DIN 17182: May 1992. DICAST is a fully killed steel, vacuum-degassed
and processed to a fine grain size structure with improved properties both in toughness and in elongation.

Certifications

After Sales Service

ZTIC Heavy Industries is your business partner in the After Market.
ZTIC  able to provide:
1.    ENGINEERED SPARES -  DESIGN AND MANUFACTURING
2.    LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3.    HUGE MACHINE SHOP CAPABILITIES
4.    TRAINING PROGRAMMES
5.    PREVENTATIVE MAINTENANCE PROGRAMS
6.    PREVETATIVE MAINTENANCE SERVICES
7.    COMPREHENSIVE MAINTENANCE PROGRAMS
