• Model NO.：C41-100KG
• Surface Treatment：Hot Galvanized
• Forging Tolerance：+,-0.2mm
• Standard：DIN
• Certification：CE, RoHS, ISO 9001:2000
• Transport Package：in Plywood Case
• Specification：C41-100
• Trademark：HOTON
• Origin：China
• HS Code：84629910
• Production Capacity：50 PCS,Month

Basic Info.

Model NO. C41-100KG Surface Treatment Hot Galvanized Forging Tolerance +/-0.2mm Standard DIN Certification CE, RoHS, ISO 9001:2000 Transport Package in Plywood Case Specification C41-100 Trademark HOTON Origin China HS Code 84629910 Production Capacity 50 PCS/Month

Product Description

AIR HAMMER FEATURES:
1. The air hammer is used for forging and shaping work pieces
2.The air hammer is easy to operate through controlling the travel of top swage by a foot rest lever.
3. It's models range from 16KG to 150KG
4. It is widely used for general forging works, such as drawing out, upsetting,punching, chiseling, forging, welding, bending and twisting
5.It is also used for forging in bolster dies.
SPECIFICATIONS:

Model	Unit	C41-100
Rated weight of hammer tup	Kg	100
Maximum blow energy	Kj	1.8
Number of blows per minute	r/min	190
Bottom die surface to guide under face	Mm	340
Hammer tup axis to frame front	Mm	300
To die surface	Mm	155x 75
Bottom die surface	Mm	155 x 75
Maximum round steel can be forged(dia.)	Mm	120
Maximum square steel can be forged	Mm	110X110
Bottom die surface to the ground	Mm	763
Floor space(Long x Wide)	mm	1500x720
Machine height(above the ground)	Mm	2050
Motor type
Power	Kw	11
Speed	r/min	960
Total weight	Kg	2212
