WS Type Socket-Clevies Eyes

Zhejiang Haivo Electrical Co., Ltd.
  • Application：Hardware
  • Die Casting Method：Soluble Die Casting
  • Die Casting Machine Type：Cold Chamber Die Casting Machine
  • Machining：CNC Machining
  • Material：Aluminum Alloy
  • Surface Preparation：Deburring

Base Info

  • Specification：ANSI, IEEE, IEC
  • Transport Package：Carton
  • Certification：ISO 9001:2000
  • Casting Surface Quality Level：2
  • Tolerance Grade：7
  • Pressure Chamber Structure：Horizontal
  • Model NO.：WS
  • Trademark：HAIVOL
  • Origin：China
  • HS Code：73269090
  • Production Capacity：20, 000PCS,Month

Description

Type

Designated size of coupling

Dimensions(mm)

Rated failure load(KN)

Weight(kg)

B

C1

C2

H

Φ

W-7A

16

16

19.2

34.5

70

20

70

0.8

W-7B

16

16

19.2

34.5

115

20

70

0.92

W1-10

16

18

19.2

34.5

85

20

100

0.9

W1-12

16

20

19.2

34.5

90

24

120

1.3

W-12

20

20

23

42.5

90

24

120

1.4

W-30

24

32

27.5

51.0

110

39

300

3.5
