• Transport Package：Steel Frame
• Size：as Per Drawing
• Application：Casting and Forging
• Uesd for：Cast Steel
• Cast：Centrifugal and Static
• Color：Cast Steel
• Material：High Speed Steel
• Spec：Dia 250-1000
• Series：Roll Mill
• Certification：ISO 9001:2000
• Model NO.：cast steel
• Trademark：OEM
• Origin：China
• HS Code：84553000
• Production Capacity：30000t,Year

Basic Info.

Model NO. cast steel Certification ISO 9001:2000 Series Roll Mill Spec Dia 250-1000 Material High Speed Steel Color Cast Steel Cast Centrifugal and Static Uesd for Cast Steel Application Casting and Forging Size as Per Drawing Transport Package Steel Frame Trademark OEM Origin China HS Code 84553000 Production Capacity 30000t/Year

Product Description

Alloy Steel Rolls

Alloy cast steel roll is made of top grade molten steel by arc furnace and advanced casting and technology of heating processing with high intensity, excellent thermal cracking resistance, toughness and abrasive resistance, applicable to rough and medium roll of profile steel, rough mill of hot rolled strip steel and supporting roll of hot rolled strip steel. Metallographic structure of roll is made of pearlite or tempered sorbite system.


Chemical composition

Mark	C	Si	Mn	Cr	Ni	Mo
AS60A(60CrNiMnMo)	0.55-0.65	0.2-0.6	0.6-2.0	1.4-2.2	≤0.6	0.3-0.6
AS70A(70Mn2)	0.65-0.75	0.2-0.45	1.4-1.8
AS70B(70Mn2Mo)	0.65-0.75	0.2-0.45	1.4-1.8	-		0.2-0.45
AS75(75CrMo)	0.7-0.8	0.2-0.45	0.6-0.9	0.75-1.0	-	0.2-0.6
AS75A(75CrNiMo)	0.7-0.8	0.2-0.7	0.7-1.1	0.8-1.5	0.2-0.8	0.2-0.6
AS75B(75Cr3NiMo)	0.7-0.8	0.2-0.6	0.7-1.1	1.5-3.6	0.4-1.0	0.2-0.8

Physical performance

Mark             Hardness          Tensile strength       Elongation            Purpose

AS60A          45-55HS            >700Mpa                   >8                       Rough roll for cogging process of  large
                                                                                                                     profile steel with requirement to
                                                                                                                     toughness and abrasive resistance



AS70A          34-44HS            >680MPa                  >7                        Rough milling machine for medium and
AS70B          36-46HS            >680Mpa                  >7                        small profile steel, rod and wire material
AS75             36-46HS            >680Mpa                  >6                        rough roll and vertical roll for hot rolled
AS75A           35-55HS            >800Mpa                  >7                       strip steel


AS75B           40-60HS            >800Mpa                 >7                       Cogging and rough milling,support roll
                                                                                                                      for hot rolled steel




We specialize in exporting different kinds of mill rolls, such as follows:

1)CAST IRON ROLLS
Alloy Chilled Cast Iron Rolls
Alloy Indefinite Chilled Cast Iron Rolls
Pearlitic Nodular Cast Iron Rolls(Centrifugal)
Spiculate Bainitic Nodular Cast Iron Rolls(Centrifugal)
Alloy Nodular Cast Iron Rolls(Centrifugal)

2)CAST STEEL ROLLS
Alloy Cast Steel Rolls
Adamite Steel Rolls
Graphite Steel Rolls
High Speed Steel Rolls
Centrigugal Casting Hi-Carbon Steel Adamite Rings

They are mainly applied to finishing mill, hot&cold rolling mill work rolls, back-up rolls. Adamite roll or high speed steel roll used in the early finishing stands of a lot strip mill.

Description:

1)Material: Alloy Steel, Alloy Iron, Ductile Iron and so on
2)Size: According to clients' drawing
3)Standard: GB, AISI, SAE, ASTM/ASME
4)Hardness: According to clients' demand
5)Chemical Composition: According to Clients'demand.
6)Inspection: Ultrasonic Inspection, Microstructure Test
7)Packaging: Steel Frame
8)Payment: T/T or L/C

Our products are high in quality and reasonable in price. We can guarantee their quality

We can supply all kinds of Work Roll.
We hope to establish longtime cooperate relationship.
If you are interesred in our produccts,
Plese contact me without hesitate.
