• Transport Package：Cartons
• Thermal Rating：220 220
• Chemistry：Inorganic Insulation
• Maximum Voltage：<10kv
• Certification：ISO 9001:2008
• Casting Surface Quality Level：2
• Tolerance Grade：6
• Pressure Chamber Structure：Vertical
• Model NO.：25-70
• Specification：ANSI, IEEE, IEC
• Trademark：HAIVOL
• Origin：China
• HS Code：3917310000
• Production Capacity：50, 000PCS,Month

NOtypeRated voltage(kv)Rated mechanical tension load (kn)  Structure of coupling marksStructure height(mm)Min. Electric arc distance (mm)Min nominal creepage distance (mm)Full wave lightning impulse withstand voltage (peak value not less than kv)1min power frequency wet with stand voltage not less than(kv)Nos of voltage divider ring1FXBW6-10/70107016380±15
 19048011545N/A2FXBW4-35/70357016650±15
 470128023095N/A3FXBW4-35/1003510016670±15
 450126023095N/A4FXBW4-66/70667016940±15
 7001900410185N/A5FXBW4-66/1006610016940±15
 6851870410185N/A6FXBW4-110/7011070161240±15
 10353180550230Negotiable7FXBW4-110/100110100161240±15
 10153150550230Negotiable8FXBW4-220/100220100162240±30
 195063001000395Negotiable9FXBW4-220/160220160202240±30
 195063001000395Negotiable10FXBW4-330/100330100162930±40
 255090751425570Negotiable11FXBW4-330/160330160202990±40
 260090751425570Negotiable12FXBW4-330/160500160204450±50
 4000137502250740Negotiable
