End Fitting for Composite Insulators

Zhejiang Haivo Electrical Co., Ltd.
  • Application：Hardware
  • Die Casting Method：Soluble Die Casting
  • Die Casting Machine Type：Cold Chamber Die Casting Machine
  • Machining：CNC Machining
  • Material：Steel
  • Surface Preparation：HDG

Base Info

  • Specification：ANSI, IEEE, IEC
  • Transport Package：Cartons
  • HDG：Steel
  • Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
  • Casting Surface Quality Level：2
  • Tolerance Grade：6
  • Pressure Chamber Structure：Vertical
  • Model NO.：25-70
  • Trademark：HAIVOL
  • Origin：China
  • HS Code：3917310000
  • Production Capacity：50, 000PCS,Month

Description

  Lightning impulse withstand BIL(kV)   Power frequency withstand (wet) (kV) FXBW4-12/70 12 70 350 180 400 95 45 FXBW4-24/70 24 70 550 370 850 185 95 FXBW4-24/100 24 100 570 370 850 185 95 FXBW4-35/70 35 70 650 450 1000 230 105 FXBW4-35/100 35 100 670 450 1000 230 105
