As2027 Cr20mo2cu First Chamber Cement Mill Shell Liners Mill Liner Plates

Wuxi Eternal Bliss Alloy Casting & Forging Co., Ltd.
  • Standard：ASTM
  • Surface Treatment：Sand Blast
  • Material：Cr20mo2cu
  • Sand Core Type：Resin Sand Core
  • Type：Chemical Hardening Sand
  • Certification：CE, ISO 9001:2008

Base Info

  • Transport Package：Plywood Case
  • Service：OEM ODM
  • Size：According to Customer′s Drawings
  • Hardness：HRC45~58
  • Model NO.：EB5029
  • Trademark：EB
  • Origin：China
  • Production Capacity：10000 Tons Per Year

Description

Reference Standard
(ISO 21988-2005)     Nominal Chemical Composition (W%)Eqv. StandardsCSiMnNiCrMoCuPSISO 21988/JN/
HBW555XCr131.8-3.6≤1.00.5-1.5≤2.011.0-14.0≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr11)
ASTM A532 12% CrISO 21988/JN/
HBW555XCr161.8-3.6≤1.00.5-1.5≤2.014.0-18.0≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr14)
ASTM A532 15% Cr-Mo
AS 2027  CrMo 15 3
G-X 300 CrMoNi 15 2 1ISO 21988/JN/
HBW555XCr211.8-3.6≤1.00.5-1.5≤2.018.0-23.00≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr18)
ASTM A532 20% Cr-Mo
AS 2027 CrMo 20 1
G-X 260 CrMoNi 20 2 1ISO 21988/JN/
HBW555XCr271.8-3.6≤1.00.5-2.0≤2.023.0-30.0≤3.0≤1.2≤0.08≤0.08EN-GJN-HV600(XCr23)
ASTM A532 25% Cr-Mo
AS 2027 Cr27 LC & Cr27 HC
G-X 260 Cr27ISO 21988/JN/
HBW600XCr353.0-5.5≤1.01.0-3.0≤1.030.0-40.0≤1.5≤1.2≤0.06≤0.06AS 2027 Cr35ISO 21988/JN/
HBW600XCr20Mo2Cu2.6-2.9≤1.0≤1.0≤1.018.0-21.01.4-2.00.8-1.2≤0.06≤0.06AS 2027 CrMoCu 20 2 1

Special Features:

1.We adopt Sand Cast Process to make High Cr & Ni hard chute liners;

2.We do quenching & tempering treatment for high Cr & Ni hard white iron plates to achieve high hardness.

3. Cr15Mo3 castings: more than HRC56; AS2027 Cr27 castings: more than HRC59; Ni-hard white iron: more than HRC54.

One Set Of Cement Mill Liners Include 8 Parts

· Shell Liners for the First Chamber ,the Second Chamber,the Third Chamber;

· Lifting Liners

· Step Liners

· Wave Liners

· Corrugated Liners

· Inter End Liners

· Inter mediated Diaphragm Liners(Grate Liners,Blind Liners)

· Outlet End Liners

As2027 Cr20mo2cu First Chamber Cement Mill Shell Liners Mill Liner Plates
As2027 Cr20mo2cu First Chamber Cement Mill Shell Liners Mill Liner Plates
As2027 Cr20mo2cu First Chamber Cement Mill Shell Liners Mill Liner Plates
As2027 Cr20mo2cu First Chamber Cement Mill Shell Liners Mill Liner Plates
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5~10 days if the goods are in stock.Or it is 45 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment.
irrevocable LC at sight.
