• Model NO.：Casting Products
• Coating：Diatomite powder
• Machining Tolerance：0.005mm-0.01mm-0.1mm
• Standard：ASTM,AISI,JIS,DIN etc
• Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008, as Customer Requests
• Material：304, 316, 304L, 316L etc. as Clients Require
• Manufacturing Process：Investment Casting, Stainless Steel Casting
• Casting Tolerance：CT4-8 for Investment Casting Products
• Finish Machining Process：CNC Machining, Lathing, Milling, Turning, Boring,
• Heat Treatment：Normalization, Annealing, Quenching and Tempering
• Surface Finish：Surface Passivation, Electric Polish
• Rough Surface Roughness：Ra3.2-25
• Package of Investment Casting Products：Multilayer Wooden Box,Pallet, with Big Plastic Bag
• Lead Time：45 Days for Investment Casting Products
• Service：Custom Investment Casting Products
• Transport Package：Multilayer Wooden Box with Big Plastic Bag Inside
• Specification：SGS, ISO9001, as clients require
• Trademark：Matech
• Origin：Zhejiang
• HS Code：8432900000
• Production Capacity：150tons,Month of Casting Products

Item Name

Chassis Bracket Stainless Steel Precision Investment Casting Products

 General Products

 Application/Service Area

Metal Parts Solution for Vehicle, Agriculture machine, Construction Machine, transportation equipment, Valve and Pump system, Agriculture machine metal Parts, engine bracket, truck chassis bracket, gear box , gear housing , gear cover, shaft, spline shaft , pulley, flange, connection pipe, pipe, hydraulic valve , valve housing ,Fitting , flange, wheel, fly wheel, oil pump housing, starter housing, coolant pump housing, transmission shaft , transmission gear, sprocket, chains etc.

 Main blank Process for Steel  Casting



Investment  casting (wax mold made by middle temperature wax) /Precision  casting ;

Lost Wax Casting (wax mold made by low temperature wax)/ Precision  casting;



 Blanks Tolerance -Casting  Tolerance

CT7-8 for Lost wax Casting Process

CT4-6 for Investment casting Process

 Applicable Material

Carbon steel, Low Carbon steel, middle carbon steel, G35, G45, WCB, WCA, WCC,  ISO 340-550,



Alloy Carbon steel: G25CrMo4, Heat Resistant Steel,



Stainless Steel:  CF8,  CF8M, . G-X6CrNiMo1810, G-X7CrNiNb1189, SUS 304, 304L, 316, 316L.

OR According to customer requirement

 Casting Blank Size  /Dimensions

2 mm-600mm / 0.08inch-24inch  according to customer requirement

 Casting Blank Weight

Range from 0.01kg-85kg

 Applicable Machining Process



CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling/ Tapping/ Broaching/Reaming /Grinding/Honing and  etc.



 Machining Tolerance

From 0.005mm-0.01mm-0.1mm

 Machined Surface Quality

Ra 0.8-Ra3.2 according to customer requirement

 Applicable Heat Treatment



Normalization , annealing, quenching and tempering, Case Hardening, Nitriding, Carbon Nitriding, Induction Quenching



 Applicable Finish Surface  Treatment

Shot/sand blast, polishing, Surface passivation, Primer Painting , Powder coating, ED- Coating, Chromate Plating, zinc-plate, Dacromat coating, Finish Painting,

 MOQ for mass production

For Investment Casting Products: 100pcs

For machining: 50pcs

 Lead Time

45 days for Investment Casting Products



FAQ:

1. What do you do?We are a professional manufacturer with over 15 years' export experience for designing and producing vehicle machinery parts.
 2. How can I get some samples? If you need, we are glad to offer you samples for free, but the new clients are expected to pay the courier cost, and the charge will be deducted from the payment for formal order.

3. Can you make Investment Casting Products according to our drawing?Yes, we can make Investment Casting Products according to your drawing, 2D drawing, or 3D cad model. If the 3D cad model can be supplied, the development of the tooling can be more efficient. But without 3D, based on 2D drawing we can still make the samples properly approved.

4. Can you make Investment Casting Products based on our samples?Yes, we can make measurement based on your samples to make drawings for tooling making.

5. What's your quality control device in house?We have spectrometer in house to monitor the chemical property, tensile test machine to control the mechanical property and UT Sonic as NDT checking method to control the casting detect under the surface of Investment Casting Products.
