• Transport Package：Plywood Case or Iron Pallet Packing
• Tolerance：as Drawing
• Dimensions：OEM Customized,Customer′s Drawing
• Inspection：Mt,Ut,Rt,100% Visual+100% Gage,CMM
• Machining Facility：20 Machining Centers+50 Nc Machines
• Heat Treatment：Quench and Temper by 2 Set Mesh Belt Furnaces
• Certification：ISO 9001:2008, Ts16949,ISO14001,TUV
• Standard：ASTM. AISI. DIN. BS. JIS. NF. as. AAR
• Machining Tolerance：+,-0.01mm
• Surface Roughness：Ra12.5
• Model NO.：mining machinery component
• Specification：parts casting
• Trademark：LX
• Origin：Ningbo, Zhejiang, China
• HS Code：87081000
• Production Capacity：20000 Tons,Year

Item NameMining Casting Part with Lost Wax Casting  General products
Application/service AreaTrain and railway casting parts, automobile and truck casting parts, construction machinery and forklift casting parts, agricultural machinery casting parts ect.Main process for steel CastingInvestment water glass lost wax castingStandardGB.ASTM.AISI.DIN.BS.JIS.NF.AS, AAR etcApplicable MaterialCarbon steel,
Low alloy steel,
Stainless Steel,
Iron or according to customer requirementCasting weight ratio0.1-5kg:40%
5-20kg:30%
20-40kg:20%
40-90kg:10%Product use ratioComponents for train & railway:25%
Components for automobile & truck:30%
Components for construction machinery & forklift:25%
Components for agricultural machinery:10%
Other machinery compponents:10%Machining processTurning,milling,drilling,boring,threading,grinding machine,CNC/NC machining and test facilitiesHeat treatmentQuench and temper by 2 set mesh belt furnacesApplicable finish surface treatmentShot/sand blast, polishing, Surface passivation, Primer Painting , Powder coating, ED- Coating, Chromate Plating, zinc-plate, Dacromat coating, Finish Painting,
Technology specification
Casting process:Water glass process of lost wax investment casting
Material range:Carbon steel, low alloy steel, stainless steel
Material standard:GB, ASTM, AISI, DIN, BS, JIS, NF, AS, AAR
Max linear size:1200mm, Max diameter size:600mm
Casting weight range:0.1-90kg
Casting Dimension tolerance:CT7
Casting surface roughness:Ra 12.5um
Applicable fields for our products:Train, railway, automobile, truck, construction machinery, mining machinery, forklift, agricultural machinery, shipbuilding, petroleum machinery, construction, valve, pumps, electric machine, hardware, power equipment and so on.

Application
Train & railway, automobile& truck, construction machinery, forklift, agricultural machinery, shipbuilding, petroleum machinery, construction, valve and pumps, electric machine, hardware, power equipment and so on.
