• Model NO.：Fg-017
• Surface Treatment：Passivation
• Forging Tolerance：+,-0.5mm
• Standard：AISI
• Certification：CE, ISO 9001:2008
• Surface：Powder Coating,Acid Pickling,Paint
• Quality Control：Strict Inspection as Per Standard
• Senior Engineers：10 Senior Engineers with 40 Years of Experience
• Product：Casting
• Transport Package：Standard export package or as per your requirement
• Specification：ISO standard
• Trademark：SYI
• Origin：China
• Production Capacity：1000 Tons per month

Close die forging

1) Suitable for:
big bath & medium size
2)  Commonly used materials
1)     Wind power shaft:42CrMo4V, 34CrNiMo6,Wind power flange: S355, C22, 16Mn, 20Mn, 42CrMo, F304

2)      Forged pipe fittings: SA106 CL B, SA 106 CL C, WB36, 12Cr1MoV, SA 335 P11, P12, P22, P91, SA182 Gr. F1, Gr. F5, Gr. F11 CL2, Gr. F12 CL2, Gr. F22 CL3, SA350 Gr. LF1, Gr. LF2, Gr. LF3,

3)      Pressure vessel forgings: SA105, SA350 LF2, 16Mn, 20MnMo, 15MnMo, 12Cr2Mo1, 14Cr1Mo, F304, F316,17-4PH

4)      Shaft related forgings: 25CrMo4, 42CrMo4, 40CrNiMo, 34CrNi3Mo, 25Cr2Ni4MoV, 18CrNiMo5, 30CrMo, 4130,4140

5)      Gear related forgings:35CrMo, 34CrMo4, 4137, 42CrMo, 4140, SCM440, 20CrMnMo, 40CrNiMo, 20CrNi2Mo, 20Cr2Ni4A, 34CrNi3Mo
3) Industry involved:
Automotive industry/Engineering/^.
4) Part overall dimension limit:
max 4000tons
Hot die forging press: up to 2500tons
Electronic hydraulic hammer: up to 5tons
5) Representative product:
Auto connecting rods/Steering engines/Gears/Driving shafts/Vehicle axles
6) Manufacturer Certification:
ISO9001 (2000)/TS16949
7)feature
Precision forging hammers range from 160 tons till 4000 tons

-Precision CNC machining centers for further machining process

-Induction furnace for raw material heating

-Heat treatment of continuous quench + temper +carburization available


8)Annual forging capacit
8000toms
9) the unit weight of forgings
range from   0.1kg/pc till 200kg/pc
10) Mold    development ability
According to the customer's drawing or sample.
