H/50 Hot Chamber Die Casting Machine
K&E Machinery (Ningbo) Co., Ltd.- Material：Zinc Alloy
- Machining：Machining Center
- Die Casting Method：Precision Die Casting
- Die Casting Machine Type：Hot Chamber Die Casting Machine
- Pressure Chamber Structure：Vertical
- Certification：CE, ISO 9001:2000
Base Info
- Transport Package：Wooden Pallet
- Easy Broken Parts：1
- Commercial Invoice：1
- Packing List：1
- Certificate of Fumigation：1
- Certificate of Origin：1
- Model NO.：H,50
- Trademark：K&E
- Origin：China
- HS Code：8454309000
- Production Capacity：200,Y
Description
Basic Info.
Model NO. H/50 Certificate of Origin 1 Certificate of Fumigation 1 Packing List 1 Commercial Invoice 1 Easy Broken Parts 1 Transport Package Wooden Pallet Trademark K&E Origin China HS Code 8454309000 Production Capacity 200/YProduct Description
| Clamping Force | KN | 500 |
| Open stroke | mm | 210 |
| Space between Tie-bar | mm | 290*290 |
| Die-thickness(Min-Max) | mm | 120-320 |
| Injection Force | KN | 50 |
| Injection stroke | mm | 110 |
| Injection position | mm | 0-40 |
| Ejector force | KN | 50 |
| Ejector stroke | mm | 50 |
| Sleeve diameter | mm | 50 |
| Pump pressure | Mpa | 10.5 |
| Motor power | KW | 9.5 |
| Injection weight | Kg | 1.1 |
| Pot capacity | Kg | 160 |
| Tank capacity | L | 320 |
| Machine weight | Kg | 3500 |
| Dimension of machine | mm | 3500*1450*2100 |
