Mixing Blades Ceramics Casting Wear Parts Wear-Resistant Blades Replace High Chromium ...

Wuxi Eternal Bliss Alloy Casting & Forging Co., Ltd.
  • Material：Ceramics
  • Application：Machinery Parts
  • Sand Core Type：Resin Sand Core
  • Type：Chemical Hardening Sand
  • Surface Treatment：Sand Blast
  • Standard：As2074 L2b

Base Info

  • Trademark：EB
  • Specification：AS 2074,L2B, AS 2074,L2C
  • Transport Package：Wooden Case
  • Hardness：Hb310-380
  • Certification：ISO 9001:2008
  • Model NO.：EB6067
  • Origin：China
  • Production Capacity：50000kg,Year

Description

Overview Our Advantages



Design concept



A. The contour of the conveying spiral blade to the bolt hole boss area adopts a pre-stressed structure design. Under the same thickness, the pre-stressed structure design can greatly improve the overall strength of the conveying blade.
B. The screw hole is changed to a capsule type. In high wear-resistant materials, the bolt hole is the weakest part of the blade. Therefore, the design of the bolt head is very important. We design the bolt head into a capsule type. The capsule-shaped bolt head hole can effectively reduce the stress generated during the manufacturing process of the conveying spiral blade, avoid sharp corner cracks, and greatly improve the overall working strength and reliability of the blade.
C. The screw hole of the capsule bolt head adopts the transverse design on the conveying blade. The horizontally designed capsule-shaped screw holes can enhance the strength of the entire blade. The width of the capsule bolt head hole is the same as the diameter of the screw hole.
D. Adopt large-area integrally intersecting bolt hole boss design. The integral bolt hole boss is in the design of high wear resistance, high hardness and brittle material, which is conducive to the fixation of bolts, which is more conducive to improving the overall strength of the blade, and greatly improving the service life and reliability of the conveying spiral blade.
E. The bolt hole boss is designed into a gate shape (as shown in the figure). The gate structure is conducive to the overall stress structure design of the ceramic blade,
F. Under the premise of the overall stress structure, the bolt boss can also be designed to be round.


Mixing Blades Ceramics Casting Wear Parts Wear-Resistant Blades Replace High Chromium White Iron Screw Conveyor Blades
Mixing Blades Ceramics Casting Wear Parts Wear-Resistant Blades Replace High Chromium White Iron Screw Conveyor Blades
Mixing Blades Ceramics Casting Wear Parts Wear-Resistant Blades Replace High Chromium White Iron Screw Conveyor Blades
Mixing Blades Ceramics Casting Wear Parts Wear-Resistant Blades Replace High Chromium White Iron Screw Conveyor Blades
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5~10 days if the goods are in stock.Or it is 45 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment.
irrevocable LC at sight.
