Pattern Carrier for Hws Mold Molding Machine
Weifang Foundry Machinery Co., Ltd.- Type：Clay Wet Sand
- Casting Method：Sand Casting
- Sand Core Type：Clay Sand Core
- Application：Moulding Line
- Machining：Machining Center
- Material：Gg25,Ggg50
Base Info
- Model NO.：WFFM
- Surface Treatment：Spray-Paint
- Surface Roughness：Ra0.2
- Standard：AISI
- Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008, D-U-N-S
- Coating Coulour：Silver
- Weight：1900kg
- Production：Customers Drawing or We Provide
- Pattern Type：Wooden Pattern
- Moulding Line：Automatic Moulding Line
- Sample Time：45 Days
- Accessories：Bushes and Pins
- Degree of Adaptability：Identity and Interchangeablility
- Other Requirements：Anti-Rust Oil and Painting Treatment
- OEM Service：Yes
- Dimension Inspect：CMM
- Material Inspect：Metallographic
- Vulnerable Part：Block,Pins and Bushes
- Flask Castings：Heat Treatment
- Visual Check：Needed
- Transport Package：Wooden Pattern
- Specification：1500X1200X450,400
- Trademark：WFFM
- Origin：Weifang, China
- HS Code：84801000
- Production Capacity：4000 Tons
Description
pattern carrier for HWS Mold Molding Machine
Bolster and Stripper Assembly is used to support mold box, match plate and pattern for mold preparation with green sand in high pressure molding machine.
Quality Inspections:
The products go through a series of strict quality control before leaving the factory.
- Surface Test: no sticky sand, sand, burrs and cracks; CMM; hardness test.
- Material Test: Chemical components analysis.
- Mechanical test, including tensile strength test.
