• Specification：2strands
• Transport Package：Plywood and Steel Frame
• Technology：Italy
• Fundction：Produce Special Alloy
• Output：220X220mm Billets
• Original：Shanghai China
• Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Standard：AISI
• Machining Tolerance：+,-0.01mm
• Coating：Water
• Model NO.：R6-4S
• Trademark：semc
• Origin：China
• HS Code：8454302900
• Production Capacity：100unit,Month

Basic Info.

Model NO. R6-4S Coating Water Machining Tolerance +/-0.01mm Standard AISI Certification CE, RoHS, ISO 9001:2000, ISO 9001:2008 Original Shanghai China Output 220X220mm Billets Fundction Produce Special Alloy Technology Italy Transport Package Plywood and Steel Frame Specification 2strands Trademark semc Origin China HS Code 8454302900 Production Capacity 100unit/Month

Product Description

We provide R6-4S CCM

R6m, 4strands, 6meter billets
Design according ITALY technology,Italy CCM OEM factory.
Biggest CCM factory with 500worker in china.
                                                                NO: R64T6m
. Technical data

1. CCM

Casting radius: R6m
Billet specification: 100x100mm,120x120mm,150X150mm
Strand number: strands 4 strands
Dummy bar: rigid dummy bar
Ladle support: Ladle Rotor Tower
Cutting way: automatic hydraulic cutting machines
Electrical system: SIEMENS/DELTA Transducer, SIEMENS/DELTA PLC, SCHNEIDER contactors . PLC automatic controlling
Billets Size: 6m
Pusher-type: hydraulic pressure system ,Mechanical car type.
2. Water system
a. Mould cooling water
Influent pressure: P≥0.9Mpfa
Influent temperature: ≤35ºC
Influent effluent temperature difference: 6-10ºC
PH:7.5-9
Water total hardness: ≤150mg/L
Withdrawal straightening machine
Power: 11KW/set
Rated revolution: 1500/min
Billet withdrawing force(max): 11000N
Straightening force (max): 220000N
Tension speed range: 0.3-3.0m/min
Dummy bar speed (max): 3.99m/min
4. Central hydraulic station
System pressure: P≥8.0MPa
System flow: Q=37.5L/min


. Supply cope
1. On-line equipment list

No	Equipment name	Unit	Qty.	Remark
1	Ladle Rotor Tower	PC	1	Double arm 100ton(not included ladle)
2	Tundish moving car	PCS	2
3	Tundish	PCS	2
4	100sq.mm mould	PCS	4
5	Mould cover	SETS	4
6	Oscillation device	SETS	4	Complete leaf spring oscillation table( Advance technology,almost no wear and tear ,long working time,top quality) Main parameter Oscillation frequency: 50~205/min Amplitude: 2.5~6 mm
7	Secondary cooling manifold (stainless steel) and support	SETS	4
8	Guide section for secondary cooling	SETS	4
9	Steam drainage system in the secondary cooling system	SET	0	Operational
10	Withdrawal straightening machine	SETS	4
11	Dummy bar	PCS	4
12	100sq Dummy head and transition head	SETS	4
13	Dummy bar guide wheel	SETS	4
14	Dummy bar storage device	SETS	4
15	Dummy bar heat protetion cover	PCS	4
16	Roller table before cutting	Group	4
17	Transmit roller table	Group	4
18	Discharge roller table	Group	4
19	Transverse pusher	SET	1
20	Cooling bed	SET	1
21	Overflow chute	PCS	4
22	Hydraulic station system	SET	1
23	Cooling water distribution system	SETS	4
24	Electrical system	SETS	3
a	Power supply conbinet	SET	1
b	Frequency conbinet	SETS	3
c	PCL conbinet	SET	1
d	Main operating table	SET	1
e	Suspension operating box	SETS	4
f	Small operating box	SETS	4
27	Steel structure platform	Batch	1
a	Main operating platform
b	Temperature test platform
c	Dummy bar storage platform

2,Auxiliary equipment

No.	Equipment name	Unit	Qty.	Remark
1	Water pipe, connector valve .etc	Batch	1
2	Various cable,tube.etc	Batch	1
3	Drainage gun	PCS	0
4	Cutting gun	PCS	0



1. Price: 865000 USD FOB Shanghai.   Complete leaf spring oscillation table
2. Price: 825000 USD FOB Shanghai.   Half leaf spring oscillation table
3. Price:  755000 USD FOB Shanghai.   Half leaf spring oscillation table with Ladle moving car.



1. Lead time: 100 days

4. Term of payment: 40% advance payment by T/T, 60% balance payment by T/T before date of shipment
5. Customer service: All the costs of seller's experts go and work at abroad for return air tickets, accommodation and meals, will be borne by the buyer. The buyer shall compensate the experts at USD 150 per engineer per day for debugging period. After normal operation the seller should be responsible to guarantee repair or change of the faulty components in 6 months, such as master control board, reactor, compensate capacitor, hydraulic device, breaker, and furnace shell (except for lining break through, stoppage or shortage of cooling water supply for components).
Delivery by 1 piece frame container, 12 piece 40HQ container
