Q/Qp Type Die Casting Ball Eyes

Zhejiang Haivo Electrical Co., Ltd.
  • Application：Hardware
  • Die Casting Method：Soluble Die Casting
  • Die Casting Machine Type：Cold Chamber Die Casting Machine
  • Machining：CNC Machining
  • Material：Aluminum Alloy
  • Surface Preparation：Deburring

Base Info

  • Specification：ANSI, IEEE, IEC
  • Transport Package：Carton
  • Certification：ISO 9001:2000
  • Casting Surface Quality Level：2
  • Tolerance Grade：7
  • Pressure Chamber Structure：Horizontal
  • Model NO.：Q, QP Type
  • Trademark：HAIVOL
  • Origin：China
  • HS Code：73269090
  • Production Capacity：20, 000PCS,Month

Description

typeDimensions(mm)Designated size of couplingRated failure load(KN)Weight(kg)dΦbd 1hQ-717221633.35016700.3QP-717201633.35016700.3QP-1017201633.350161000.3QP-1221242041.060201200.5QP-12G17241733.360161200.4QP-1621262041.060201600.5QP-16G21261841.060201600.5QP-2025302449.080242001.0QP-21D21302441.070202100.9QP-3025392849.080243001.1QP-2120G21262041.080202100.7QP-3224G25332849.080243201.2QP-4228G29393257.0100284201.5
