• Model NO.：sand making crusher
• Certification：CE, ISO 9001:2008
• Color：Red, Black, Yellow Jaw Crusher Spare Parts
• Wooden Tray Package：High Manganese
• Brand：Denp
• Transport Package：Wooden Tray
• Specification：GB
• Trademark：DP
• Origin：China
• HS Code：84742090
• Production Capacity：5000t,Y

Basic Info.

Model NO. sand making crusher Certification CE, ISO 9001:2008 Color Red, Black, Yellow Jaw Crusher Spare Parts Wooden Tray Package High Manganese Brand Denp Transport Package Wooden Tray Specification GB Trademark DP Origin China HS Code 84742090 Production Capacity 5000t/Y

Product Description

Best Sale Sand Making Pusher Crusher Spare Parts


Material	C	Mn	Si	Cr	P	S
Mn13Cr2	C:1.0~1.3	Mn:11~14	Si:0.3~0.6	Cr:1.7~2.4	P:≤0.05	S:≤0.03
Mn18Cr2	C:1.1~1.4	Mn:17~20	Si:0.3~0.6	Cr:1.7~2.4	P:≤0.05	S:≤0.03
Mn21Cr2	C:1.1~1.4	Mn:20~24	Si:0.3~0.6	Cr:1.7~2.4	P:≤0.05	S:≤0.03

DENP DPI crusher is designed by reputed German expert of DENP and every index of VSI crusher is in world's leading standard. DENP DPI crusher incorporates three crushing types and it can be operated 720 hours continuously. Nowadays, DPI crusher has replace hammer crusher, roller crusher, roller ball mill, etc. And become the mainstream equipment in sand making business.
Technological advantages:
DPI crusher incorporates three crushing styles; Its feeding style incorporates material on material, materials on iron and falling at sides. Customers can adjust the machines according to their own demand. DPI crusher realizes multiple functions in one machine, which is a big breakthrough in sand making field.
Specifications:

DENP-DPI crusher (Hydraulic) Key Specification:
ModelDPI7611DPI8518DPI9526DPI1140
Capacity (t/h)Feed both at center and at sides120-180200-260300-380450-520
Feed at center60-90100-130150-190225-260
Max. Feeding size (mm)Soft material< 35< 40< 45< 50
Hard material< 30< 35< 40< 45
Rotation speed (r/min)1700-18901520-16901360-15101180-1310
Double motor power(KW)2× 552× 902× 1322× 200
Overall dimension (L× W× H) (mm)4100× 2248× 25334378× 2350× 26674640× 2650× 28005570× 2900× 3000
Weight (t)7.810.31625.6
Power supplyAC380V, 50Hz
Vibrating sensordetect range: 0.1-20mm/s continous and adjustable
Lubrication
And Hydraulic Pressure stationDouble oil pumps motor's power (KW)2× 0.31kw
Safty AssuranceDouble oil pumps assure enough oil supply; Switch off automatically without oil flow or oil pressure. Lower the temperature with cool water in summer raise the temperature with motor in winter.
Overall dimension (L× W× H) (mm)820mm× 520mm× 1270mm
Power of oil Tank Heater2kw
