• Model NO.：C41-16
• Surface Treatment：Forging
• Forging Tolerance：+,-0.1mm
• Standard：DIN
• Certification：CE, RoHS, ISO 9001:2000
• max.hit energy：0.18kj
• hit number：258
• speed：1440rpm
• weight：290kgs
• power：1.5kw
• Transport Package：Plywood Case
• Specification：290kgs
• Trademark：HOTON
• Origin：Shandong, China
• HS Code：8462109000
• Production Capacity：20PCS,Month

Basic Info.

Model NO. C41-16 Surface Treatment Forging Forging Tolerance +/-0.1mm Standard DIN Certification CE, RoHS, ISO 9001:2000 max.hit energy 0.18kj hit number 258 speed 1440rpm weight 290kgs power 1.5kw Transport Package Plywood Case Specification 290kgs Trademark HOTON Origin Shandong, China HS Code 8462109000 Production Capacity 20PCS/Month

Product Description

AIR HAMMER PRODUCT FEATURES:
The air hammer is easy operation ,flexible movement and convenient to transit ,
installation ,maintenance ,the type is widely used for various of free forging works ,
such as drawing out ,upsetting ,punching ,chiseling .forging welding ,bending and twisting .
It is also used for open die forging in bolster dies.
it is suitable for free forging works of all kinds of different shape parts ,
especially suitable for village township enterprise and self-employed forge small agriculture tools .
For example sickle ,horseshoes ,Spike ,hoe etc .
At the same time ,the industrial enterprise use the air hammer to forge the steel ball ,
scaffold and many other factories and mines ,construction supplies .
In addition the series air  hammer is very commonly professional blacksmith's iron tools
that can install all kinds of mould to forge a variety iron flowers ,birds and other beautiful decoration.
SPECIFICATIONS

SPECIFICATION	UNIT	C41-16KG SINGLE WITH BASE PLATE
Weight of falling parts	Kg	16
Max. hit energy	KJ	0.18
Height of working area	mm	180
Hit number	min-1	258
Dimension of top and bottom die surface (L*W)	mm	70×40
Max. square steel can be forged	mm	20×20
Max. round steel can be forged (Diameter)	mm	Φ22
Rate Power	KW	Single 1.5/220 Three phase 1.5/380
Speeds of motor	r.p.m	1440
Weight of base plate	kg	40
Total weight	kg	290
Overall dimensions(L*W*H)	mm	800×420×1170
