Lost Wax Casting Vacuum Casting High Temperature Alloy Turbo

Weifang Boyuan Power Technology Co., Ltd.
  • Casting Method：Vacuum Casting
  • Process：Lost Wax Casting
  • Molding Technics：Silica Sol Process
  • Application：Turbojet Engine
  • Material：Inconel713c
  • Surface Preparation：Sand Blast

Base Info

  • Model NO.：W26.1
  • Surface Roughness：Ra3.2
  • Machining Tolerance：+,-0.01mm
  • Standard：ASTM
  • Certification：ISO9001:2015
  • Tensile Test Temperature：Above 900 Degree
  • Tensile Strength of High Temperature：Above 830MPa
  • Elongation of High Temperature：Above 3%
  • Persistent Creep Temperature at High Tem：Above 975 Degree
  • Creep Tensile Strength at High Temperatu：Above 225MPa
  • High Temperature Duration：Above 40h
  • Test of Surface Defect：Fpt
  • Test of Internal Defect：X-ray
  • Test of Size：CMM
  • Transport Package：Plywood Boxes
  • Specification：Diameter: 500mm
  • Trademark：BoYuan casting
  • Origin：China
  • HS Code：8414909090
  • Production Capacity：100000pieces,Years

Description

Overview Product Description

    Superalloy turbine wheel used for turbojet engine, turbine wheel be finished by integral casting. And casting method of turbine wheel is investment & vacuum casting, casting surface smoothness can meet Ra3.2μm.

   The material of turbine wheel is superalloy Inconel713c. And all turbine wheel  are subjected to stress relief heat treatment to imporve the mechanical properties of products. After heat treatment mechanical properties can meet:

Detailed Photos



Company Profile

Our Advantages

1. We can finish mould design and mould machining, mould assembly in our factory to ensure plan of casting
2. We can finish all casting and machining in our factory to ensure production time
3. We can finish all inspection in our factory to ensure production quality
Lost Wax Casting Vacuum Casting High Temperature Alloy Turbo

Packaging & ShippingProduct Parameters

Production Capacity/ material of casting and machining

FAQ

1.What materials do you cast and machining?
We can cast and machining aluminum alloy parts and high temperature alloy parts.

2. How can I get the quotation?
Please send us information for quote: drawing, material, weight, quantity and request.

3.If we don't have drawing, can you make drawing for me?
Yes, we make the drawing of your sample and duplicate the sample.

4.When can I get the sample?
Sample: 25-30 days after you start to make mold. The accurate time depends on your product.

5.What is your main order time?
Order time: 30-40 days after the payment. The accurate time depends on your product.

6. What is your payment method?
Tooling: 100% TT advanced.
Batch order: 50% deposit, balance 50% to be paid before shipment.

7. Which kind of file format you can read?
PDF, ISGS, DWG, STEP, STP,X-T...
