Wear Resistant Cast Liner Plate/Cr26 Liner Plate

Shenzhen DENP Industrial Co., Ltd.
  • Casting Method：Sand Casting
  • Casting Form Material：Metal
  • Casting Metal：Cast Steel
  • Casting Form Usage Count：Permanent
  • Surface Treatment：Polishing
  • Color：Customized

Base Info

  • Model NO.：Liner Plate
  • Brand：Denp
  • Material：High Manganese
  • Transport Package：Wooden Tray Package
  • Specification：GB
  • Trademark：DP
  • Origin：Shanghai
  • HS Code：84749000
  • Production Capacity：5000 T,Y

Description

ModelFeeding Hole Dimension(mm)Maximum Feeding size (mm)Rotor Dimension(mm*mm)Handling Ability (t/h)Power(kw)Overall Dimension (mm*mm*mm)Weight(t)PF1007400*730250Φ1000*70030~5037-552440*1580*267209.8PF1010400*1080250Φ1035*105050~8055/902280*1804*238912.8PF1210400*1080350Φ1250*105070~1201103165*2027*272914.6PF1214400*1430350Φ1250*140095~145132/1602571*2403*270517PF1315860*1520350Φ1320*1500150~2002203154*2695*261321.5PF1320860*2030500Φ1320*1200200~2803153320*3218*261325PF14161052*1652500Φ1420*1600280~3503553405*2813*271329PF15202040*1315700Φ1512*2000350~450400/4504138*3422*364944PF16202040*1315700Φ1612*2000400~6005004236*3572*373547PF18201620*2040700Φ1800*2000550~800630/7104471*3250*400866PF20241800*24301200Φ2000*2400800~110011204800*4740*4180115PF23252210*25401500Φ2300*25001000~14001250/14005360*5075*4679158Wear Resistant Cast Liner Plate/Cr26 Liner PlateWear Resistant Cast Liner Plate/Cr26 Liner Plate
