• Model NO.：oem custom made machining steel sand casting parts
• Coating：Zinc oxide
• Machining Tolerance：CT4-8 for Steel Casting
• Standard：According to Customer Requirement
• Certification：CE, RoHS, ISO 9001:2000, ISO 9001:2008, Ts16949
• Customized：Customized
• Application：Machinery Parts
• Material：G25crmo4, G35, Wcb
• Blank Process：Investment Casting, Option Lost Wax Casting
• Casting Tolerance：CT4-8 for Custom Made Machining Steel Sand Casting
• Machining Process：CNC Machining, Lathing, Milling, Turning, Boring,
• Machining Tolearnce：up to It7, Ra 0.8~3.2
• Lead Time：45 Days for Custom Made Machining Steel Sand Casti
• Service：Supply Metal Parts Solution as Per Customer′s Draw
• Casting Blank Size：as Customer Request
• Transport Package：Multiplayer Wood Box with Big Plastic Bag Inside
• Specification：Customized Size
• Trademark：Matech Industry
• Origin：China Shanghai
• HS Code：8907900090
• Production Capacity：200ton,Month

 General Products
 Application/Service Area
Metal Parts Solution for Vehicle, Agriculture machine, Construction Machine, transportation equipment, Valve and Pump system, Agriculture machine metal Parts, engine bracket, truck chassis bracket, gear box , gear housing , gear cover, shaft, spline shaft , pulley, flange, connection pipe, pipe, hydraulic valve , valve housing ,Fitting , flange, wheel, fly wheel, oil pump housing, starter housing, coolant pump housing, transmission shaft , transmission gear, sprocket, chains etc.
 Main blank Process for Steel  Casting

Investment  casting (wax mold made by middle temperature wax) /Precision  casting ;
Lost Wax Casting (wax mold made by low temperature wax)/ Precision  casting;

 Blanks Tolerance -Casting  Tolerance
CT7-8 for Lost wax Casting Process
CT4-6 for Investment casting Process
 Applicable Material
Carbon steel, Low Carbon steel, middle carbon steel, G35, G45, WCB, WCA, WCC,  ISO 340-550,

Alloy Carbon steel: G25CrMo4, Heat Resistant Steel,

Stainless Steel:  CF8,  CF8M, . G-X6CrNiMo1810, G-X7CrNiNb1189, SUS 304, 304L, 316, 316L.
OR According to customer requirement


Copper alloy
Brass: HPb59-1, CuZn39Pb1/2/3, CuZn40, C36000, C37710, C67400, etc.
Aluminum Bronze: QAl11-6-6, CuAl10Fe2/3, CuAl10Ni5Fe5, C65500, C95600, C87500
Sn Bronze: CuPb5Sn5Zn5, C83600, C84400, C86500. etc.
Magnesium
 Casting Blank Size  /Dimensions
2 mm-600mm / 0.08inch-24inch  according to customer requirement
 Casting Blank Weight
Range from 0.01kg-85kg
 Applicable Machining Process

CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling/ Tapping/ Broaching/Reaming /Grinding/Honing and  etc.

 Machining Tolerance
From 0.005mm-0.01mm-0.1mm
 Machined Surface Quality
Ra 0.8-Ra3.2 according to customer requirement
 Applicable Heat Treatment

Normalization , annealing, quenching and tempering, Case Hardening, Nitriding, Carbon Nitriding, Induction Quenching

 Applicable Finish Surface  Treatment
Shot/sand blast, polishing, Surface passivation, Primer Painting , Powder coating, ED- Coating, Chromate Plating, zinc-plate, Dacromat coating, Finish Painting,
 MOQ
For steel casting: 200pcs
For machining: 50pcs
 Lead Time
45days from the receipt date of custom made machining steel sand casting parts




 FAQ:

1. What do you do?We are a professional manufacturer with over 15 years' export experience for designing and producing vehicle machinery parts.
 2. How can I get some samples? If you need, we are glad to offer you samples for free, but the new clients are expected to pay the courier cost, and the charge will be deducted from the payment for formal order.

3. Can you make custom made machining steel sand casting parts according to our drawing?Yes, we can make it, 2D drawing, or 3D cad model. If the 3D cad model can be supplied, the development of the tooling can be more efficient. But without 3D, based on 2D drawing we can still make the samples properly approved.

4.Can you make custom made machining steel sand casting parts based on our samples?Yes, we can make measurement based on your samples to make drawings for tooling making.

5. What's your quality control device in house?We have spectrometer in house to monitor the chemical property, tensile test machine to control the mechanical property and UT Sonic as NDT checking method to control the casting detect under the surface of casting. Matech Industry ltd specializes in Metal Parts Solution for Vehicle, Agriculture machine, Construction Machine, transportation equipment, Valve and Pump system.

With keeping manufacturing process design, quality planning, key manufacturing processes and final quality control in house we are mastering key competence to supply quality mechanical parts and assembly to our customers for both China and Export Market .

To satisfy different mechanical and functional requirements from our customers we are able to make a big range of metal products for our clients on base of different blanks solutions and technologies. These blanks solutions and technologies include processes of Iron Casting, Steel Casting, Stainless Steel Casting, Aluminum Casting and Forging.

During the early involvement of the customer's design process we are able to provide professional input to our customers in terms of process feasibility, cost reduction and function approach. You are welcome to contact us for technical enquiry and business cooperation.
