• Model NO.：Mill Liner
• Coating：Ball Mill Liner
• Machining Tolerance：Ball Mill Liner
• Standard：ASTM
• Certification：ISO 9001:2008
• Mill Liner：Mine Ball Mill Liner and Cement Ball Mill Liner
• Sag/AG Mill Liners：Integrated and,or Plate and Lifter Designs for Hea
• Ball Mill Liners：Single Wave Liners Modified Single Wave Liners Dou
• Rod Mill Liners：Shell Liners Head Liners "Wedge" Shell Liners
• Acceptance Standard：a. ASTM A609 B. ASTM A609 S1
• Transport Package：Ball Mill Liner
• Specification：Rotary kiln support roller
• Trademark：LYZT
• Origin：Luoyang, Henan
• Production Capacity：3000PCS,Year

Overview Product Description

Mill Liners:Ball Mill Liners, SAG/AG Mill Liners, Rod  Mill Liners

ZTIC specialized in producing wear-resist castings used in grinding equipments and main spindle bush, brake shoe for the mill of various specifications. It has strong casting, heat treatment and machining ability, strict quality and process controlled methods as well as the perfect examination and experimental means, so that can wear-resisting products enjoy high reputation in China and sells well all over the world.

GENERAL DESCRIPTION

Grinding wear parts are subjected to different combinations of impact and abrasion, as they are used in SAG/AG, ball or rod mills. Our wear parts are manufactured to the highest standards of quality, traceability and delivery, ensuring high levels of reliability for our customers. Also, our wear parts add value to customers' processes through customized designs The use of internationally recognized advanced specialized software simulation mill liners for lining structure, size to optimize the design.

Barrel and cap are made of wear-resistant liner material chrome molybdenum alloy steel, the use of convex liner, improve service life and grinding effect.
 Liner with a flat head bolts, supporting self-locking nut and ferrule. Coupling bolts with special seals to prevent leakage of plasma.
 Quantity bolted liner wealthy amount of 5%.
 Cover and cylinder liner wear-resistant rubber padding junction strip, which is fixed by the close of the liner.
 Rubber gasket between the cylinder liner and a thickness of 6mm, noise can be reduced.

SAG/AG Mill Liners:
Integrated and/or plate and lifter designs for head and shell liners
Grates
Pulp lifters
Filler rings

Ball  Mill Liners:
Single wave liners
Modified single wave liners
Double wave liners
Shell liners
Feed head liners
Discharge end liners

Rod  Mill Liners:
Shell liners
Head liners
"Wedge" shell liners
Specification for Steel Castings for Grinding Mills
Applicable Specifications
a. ASTM A609
b. ASTM A609 S1
For ASTM A 216 WCA Steel (modified):


 TypeI II III
IV


V

Linear discontinuities

Shrinkage  Inclusions


Internal Chills


Porosity

None accepted
1

Level 1
2

Level 2


All levels unacceptable
1

Level 1



FAQ

Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
     2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged      parts
     3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.

Q:Delivery time
A: parts lead time 1-2months, machines 2-3months.

Q:Payment terms
A: Accept payment type: T/T, L/C, Western union,Cash.
30% deposit when signed contract. Full payment paid before shipping

Q: Quality warranty?
A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.

Q: After sales service?
A: we can supply technical guide for machines running test and parts maintenance if end user needs.
