• Model NO.：Jaw Plate
• Machining Tolerance：+,-0.15mm
• Standard：AISI
• Certification：CE, ISO 9001:2008
• Usage：Used for Jaw Crusher
• Color：Red, Black, Yellow, etc.
• Material：High Manganese Steel
• Package：Wooden Tray Package
• Transport Package：Wooden Tray
• Specification：GB
• Trademark：DP
• Origin：China
• HS Code：84742090
• Production Capacity：5000t,Y

Basic Info.

Model NO. Jaw Plate Machining Tolerance +/-0.15mm Standard AISI Certification CE, ISO 9001:2008 Usage Used for Jaw Crusher Color Red, Black, Yellow, etc. Material High Manganese Steel Package Wooden Tray Package Transport Package Wooden Tray Specification GB Trademark DP Origin China HS Code 84742090 Production Capacity 5000t/Y

Product Description

Mandibula Movil Jaw Mn13cr2 Jaw Plate


Material	C	Mn	Si	Cr	P	S
Mn13Cr2	C:1.0~1.3	Mn:11~14	Si:0.3~0.6	Cr:1.7~2.4	P:≤0.05	S:≤0.03
Mn18Cr2	C:1.1~1.4	Mn:17~20	Si:0.3~0.6	Cr:1.7~2.4	P:≤0.05	S:≤0.03
Mn21Cr2	C:1.1~1.4	Mn:20~24	Si:0.3~0.6	Cr:1.7~2.4	P:≤0.05	S:≤0.03

Jaw plates (fixed and swing jaw plate) are the most important wear parts of jaw crusher. We use high manganese steel with chrome as the material to make sure the quality.

Raw materials are crushed to small aggregates between movable jaw plate and fixed jaw plate. So movable jaw plate impacts raw material directly during the operation-time. Supposing that it is damaged, raw materials will impact the movable jaw of jaw crusher and the machine service-life will also be affected.

Jaw crusher can reach the crushing ratio of 4-6 and the shape of final product is even. It is widely applied to crush high hardness, MID hardness and soft rocks and ores such as slag, construction materials, marble, etc. The pressure resistance strength is under 200Mpa, that is, suitable for primary crush. Jaw crusher can be used in mining, metallurgical industry, construction, road and railway building, conversancy, chemistry, etc.

Features:

Simple structure, easy maintenance;
Stable performance;
Even final particles and high crushing ratio.

Operating principle:
Jaw crusher machine uses motor as its power. Through the motor's wheels, the eccentric shaft is driven by the triangle belt and slot wheel to make the movable jaw plate move by a regulated track. Therefore, the materials in the crushing cavity composed of fixed jaw plate, movable jaw plate and side-lee board can be crushed and discharged through the discharging opening.

Features and values:
High reliability
Both casting and welded frame construction
Top crushing performance
Wedge setting adjustment
Fast and simple maintenance
Easy and less costly to install
Excellent total crushing economy
Excellent suitability
Highly versatile: Ready and able to crush all your Stones in stationary or semi-mobile installations.
